Video Management Unit
AVİES Video Management Unit directs and controls complex video streams for avionics, land and naval platforms.
![](https://avies.com/wp-content/uploads/2024/03/vmu-img-1.png)
![](https://avies.com/wp-content/uploads/2024/03/vmu-img-02.jpg)
VMU-100 is a video management device that can withstand harsh military environments, fulfill switching requirements on different types of platforms, and convert various video formats into one another.
It is the only product in its field with this scope and capability and offers an optimized solution in size, weight and power consumption.
In addition to platform-specific preferred digital video interface types, it provides analog composite video interface support for compatibility with existing and old platforms.
It also stands out by gaining advanced capabilities such as PIP with a device of low size and weight.
Technical Specifications
HD-SDI Video Input | x6 |
HD-SDI Video Output | x6 |
3G-SDI Support | Provision |
DP Video Input | x4 (2 lane) |
DP Video Output | x4 (2 lane) |
DVI Video Input | x2 |
DVI Video Ouput | x2 |
Analog Video Input | x2 |
Analog Video Ouput | x2 |
RS422 Interface | x2 |
ARINC429 Interface | x2 |
CANBUS Interface | x2 |
IEEE 802.3 Ethernet | x1 |
O/G Discrete Interface | x8 |
H264 Video Compression | Provision |
Picture-in-Picture | ✔ |
Dimension | 280 x 155 x 80 mm |
Weight | 2,5 Kg |
Power Usage | < 25W |
Qualifications
- DO-160G
- MIL-STD-810H
- MIL-STD-461F
- MIL-STD-704F
Environmental Conditions
Operating Temperature and Altitude: -40°C / +71°C, 50.000 ft
Storage Temperature: -55°C / +85°C
